Applications
Ideal for softening water in boiler feedwater, heating systems, cooling units, and various industrial processes. Also used for reducing water hardness in commercial or industrial applications and as a pre-treatment for reverse osmosis systems.
Performance
Raw Water Hardness | ≤5mEq/L |
Soft Water Hardness | ≤0.03mmol/L |
Water Pressure | 0.25Mpa-0.4Mpa |
Power Supply | 220V, 50HZ |
Control Method | Automatic quantity-controlled regeneration |
Standard Configurations
Control Valve | Brand: FLECK (1 unit) |
Model: 9100 |
Ion Exchange Vessel | FRP fiberglass vessels (2 pcs) |
Size: ⌀350×H1650mm |
Ion Exchange Resin | Brand: Purolite (200L) |
Model: C100E |
Brine Tank | Material: PE Volume: 200L (1 pc) |
Specifications
Model | Flow Rate (T/H) | Working Mode | Vessel Size (⌀ ×H) (mm) | Vessel Quantity | Brine Tank Volume (L) | Brine Tank Quantity (pc) | Resin Volume (L) | Control Valve Model | Operation Mode | Dimensions (L×W×H) (mm) |
ECH-R-1 | 1 | Intermittent | 250×1400 | 1 | 100 | 1 | 50 | 5600SM | Single valve, single vessel, flow rate type | 650×400×1700 |
ECH-R-2 | 2 | 300×1400 | 100 | 75 | 5600SM | 750×450×1700 |
ECH-R-3 | 3 | 350×1650 | 200 | 100 | 5600SM | 950×600×2000 |
ECH-R-4 | 4 | 400×1650 | 200 | 150 | 5600SM | 1000×600×2000 |
ECH-R-6 | 6 | 500×1750 | 300 | 200 | 2850SM | 1150×650×2200 |
ECH-R-8 | 8 | 600×1900 | 500 | 300 | 2850SM | 1400×800×2400 |
ECH-R-10 | 10 | 750×1900 | 800 | 550 | 2850SM | 1900×1100×240 |
ECH-R-15 | 15 | 900×1900 | 1000 | 700 | 2900SM | 2100×1100×2400 |
ECH-R-20 | 20 | 1000×1900 | 1000 | 850 | 2900SM | 2200×1200×2400 |
ECH-RS-1 | 1 | Continuous | 250×1400 | 2 | 100 | 100 | 9100SM | Single valve, dual vessel, flow rate type (one in operation and one standby) | 1100×500×1700 |
ECH-RS-2 | 2 | 300×1400 | 200 | 150 | 9100SM | 1200×500×1700 |
ECH-RS-3 | 3 | 350×1650 | 200 | 200 | 9100SM | 1400×650×2000 |
ECH-RS-4 | 4 | 400×1650 | 200 | 300 | 9100SM | 1500×650×2000 |
ECH-RS-6 | 6 | 500×1750 | 300 | 400 | 9500SM | 1800×800×2300 |
ECH-RS-8 | 8 | 600×1900 | 500 | 600 | 9500SM | 2000×800×2400 |
ECH-RS-10 | 10T×2 | 750×1900 | 800 | 2 | 1100 | 2850#6 | Dual valve, dual vessel, flow rate type (simultaneous operating) | 2200×2000×2400 |
ECH-RS-15 | 15T×2 | 900×1900 | 1000 | 1300 | 2900#6 | 2200×2100×2600 |
ECH-RS-20 | 20T×2 | 1000×190 | 1000 | 1800 | 2900#6 | 2400×2400×2600 |
ECH-RS-130 | 30T×2 | 1200×2300 | 2000 | 2250 | 3900#6 | 3000×2800×3000 |
ECH-RS-150 | 50T×2 | 1500×2400 | 2000 | 3750 | 3900#6 | 3500×3200×2400 |
ECH-RS-10 | 10T | 750×1900 | 800 | 1100 | 2850NT | Dual valve, dual vessel, flow rate type (one in operation and one standby) | 2200×2100×2400 |
ECH-RS-15 | 15T | 900×1900 | 1000 | 1300 | 2900#7 | 2200×2100×2600 |
ECH-RS-20 | 20T | 1000×1900 | 1000 | 1800 | 2900#7 | 2400×2400×2600 |
ECH-RS-30 | 30T | 1200×2300 | 2000 | 2250 | 3900#7 | 3000×2800×3000 |
ECH-RS-50 | 50T | 1500×2400 | 2000 | 3750 | 3900#7 | 3500×3200×3200 |
